Q-SMD7015-P4-32.768 kHz-12.5-20-4085
'-
Manufacturer: YOKETAN
-
Case size: SMD7015-P4 / T7
Frequency: 32.768 kHz
Load Capacitance: 12.5 pF
Tolerance at +25 °C: ±20 ppm
Tolerance over Temp.: f (ppm) = TC · (25 °C - T)²
……[TC: -0,030ppm/°C² typ., -0,040ppm/°C² max.]
ESR max.: 65 kOhm
Operating Temp.: -40°C/+85°C
-
Quantity: 3000 pieces/Reel
-
===============================
Country of Origin: TAIWAN
Customs-Tariff-Code: 8541600
===============================
Specifications
| Q 3.09 Shunt Capacitance C0 (pf max.) | 1.0 |
| Q 3.10 Motional Capacitance C1 (fF max.) | 3.0 |
